Yatong 200mm Plastic Profile Production Line with Film Packing

Availability:
Quantity:
  • YATONG
  • 84772010

Product Description

Yatong 200mm  Plastic Profile Production Line with Film Packing

downLoadImg (1)

Product Description

Quick Detail:

The small plastic profile extrusion line is mechanotronics, with the advantages of:
1) high production efficiency;
2) reasonable structure compact;
3) convenient operation and maintenance
4) long use life etc.

Description:

This small plastic profile extrusion line consists of single screw extrusion machine, vacuum calibrating platform, haul-off machine, cutting machine and stacker. There are many outstanding features of this small profile line, like good plasticizing, high output, low energy consumption etc.

Specification :

model YF60 YF180 YF240 YF430
extruder SJSZ-45 SJSZ-51 SJSZ-65 SJSZ-80
Max width of profile(mm) 60 180 240 300
Output  (kg/h) 70-100 80-120 160-250 300-360
Main motor power  (kw) 15 18.5 37 55
Cooling water (m3 /h) 4 5 7 7
dimension 15×1.2×1.5 18×1.2×1.6 22×1.5×1.8 26*1.6*1.8

REMARK : if the equipment or technological parameters have some change , we shall not make a notice separately

Advantage Feature:

1) Excellent weather resistance
2) Excellent heat insulation and energy saving
3) Excellent water resistance
4) Excellent sound proofing
5) Corrosion resistance
6) Excellent fire proofing
7) Attractive appearance
8) Environmentally friendly
9) Easy to clean
